What is iC60?

The Reflex iC60 integrated control circuit breaker combines the function for remote control of an installation and the protection functions of a circuit breaker in a single unit. The iMDU auxiliary is used to control the Reflex iC60 circuit breaker at 24/48 V AC/DC.

What is a VIGI unit?

A VIGI module is the low level earth fault module that can be added to a circuit breaker to make it into an RCBO. VIGI is the tradename used by Schneider/Merlin Gerin.

What are Type D circuit breakers used for?

According to the The Electrical Guide, Type D breakers protect devices such as transformers or welding machines — items that can tolerate higher surges of electricity than home appliances.

What is miniature in MCB?

An MCB is an automatically operated electrical switch. Miniature circuit breakers are intended to prevent damage to an electrical circuit as a result of excess current. They are designed to trip during an overload or short circuit to protect against electrical faults and equipment failure.

What is RCBO electrical?

Residual current circuit breaker with Overcurrent Protection
Residual current circuit breaker with Overcurrent Protection- RCBO.

What is the difference between Rccb and RCBO?

RCCB will only identify current leakage from circuit. On the other hand, RCBO can notice over current and current leakage from the circuit. The device recognizes over current in the same manner as MCB does. RCBO is usually utilized as replacement for MCB in consumer unit.

What is the difference between Type C and Type D MCB?

Type C devices are designed to trip at 5-10 times In (50-100A for a 10A device). Type D devices are designed to trip at 10-20 times In (100-200A for a 10A device).
