How wide is a 11 speed freehub?
This puts the hub at 131mm wide, which will fit into a standard 130mm spaced road frame with no problem and likely cause no alignment issues.
Are 11 and 12 speed cassettes the same width?
12 speed cassettes are almost the same width as 11 speed, so range of movement shouldn’t be an issue. The gaps between cogs is the main difference.
Can I put an 11 speed freehub on a 10 speed wheel?
It will shift fine with a Shimano or SRAM 11-speed system. And in case any of you were wondering, if you have a 10-speed Shimano or SRAM system and buy a wheelset now, you can still run 10-speed cogs on that wheel. To put a 10-speed cogset on an 11-speed freehub, you just put a spacer behind the largest cog.
What is the width of an 11 speed cassette?
Chains for 11-speed systems are around 5.4mm wide on the outside, vs. around 5.9mm wide for 10-speed ones, so that’s 0.25mm narrower from the center of the cog tooth to the end of the chain pin on each side. That’s not enough to likely even be noticeable in any difference in how it passes through the jockey wheel cage.
Are Freehubs interchangeable?
Almost always, the answer is no, there is no interchangeability between different brands – and often limited interchangeability within a brand.
How wide is a Shimano 11 speed cassette?
3. Standards by number of “speeds” and manufacturer
| TABLE 1 | Dimensions are in millimetres | |
|---|---|---|
| Shimano, SRAM 9-speed | 4.35 | 36.5 |
| Shimano, SRAM 10-speed | 3.95 | 37.2 |
| Shimano, SRAM 11-speed road* | 3.74 | 39 |
| Shimano, SRAM 11-speed MTB* | 3.9 | 40.6 |
Can you fit a 11 speed cassette on a 10 speed hub?
Yes. The 34t fits in the same way that 11spd Shimano mtb cassettes fit with the largest cog dished over the hub flange. Yep that’s the jist.. 11-32 is 11 speed road only, 11-34 is 8/9/10 spd road and 11 spd mtb compatible so will fit on your Deore 10 speed hub.
Can MTB 11 speed cassettes be mounted on 8 speed freehub?
Since MTB 11 speed cassettes can be mounted on the 8, 9 and 10 speed compatible freehub, this one is meant for road 11 speed cassettes only. 8 and 9 speed cassettes can be used with a 1.8 mm wide spacer.
What is the difference between a 10-speed and an 11-speed freehub?
When FLO started and 11-speed was in its infancy, 10-speed and 11-speed freehubs were different. In order to add the additional gear on an 11 speed freehub, more space was added to the freehub.
What’s the difference between Hg and 8-speed freehub?
While HG is the most common standard by far, there are still a few fitment pitfalls to be aware of. The first up is that there is a 7-speed specific HG freehub body. It’s shorter than the 8-speed and above design, so those cassettes won’t fit on it.
Which freehub should I use with my SRAM NX 12 speed cassette?
The Sram NX 12 speed cassette uses the Shimano HG freehub body, so you need to watch out for this one. A good way to check compatibility is to see how many teeth your Sram cassette has. If the smallest cog is 10T, it should use an XD-style freehub, but if it’s 11T then it likely uses a Shimano HG freehub.
